When innovation brings a unique design, differentiating from competition to treat highly calcified Chronic Total Occlusions.
High pushability combined with 17 atm Rated Burst Pressure and puncture resistance making every CTO easier to manage.
Avoids the flaring effect in the most calcified Total Chronic Occlusion
Increase the support and allows a better localization of the entry cup
High pushability given by the shaft design
| Reference | Balloon Diameter | Balloon Length | Marker | Tip Length | Entry Profile | Max. Guidewire | Usable Length | Min. Guide Catheter / ID |
|---|---|---|---|---|---|---|---|---|
| 110050483 | 1.1 mm | 5 mm | 1 | 1 mm | 0.016" | 0.014" | 138 cm | 5 F / 0.056" |
| 110100483 | 1.1 mm | 10 mm | 1 | 1 mm | 0.016" | 0.014" | 138 cm | 5 F / 0.056" |
| 110150483 | 1.1 mm | 15 mm | 1 | 1 mm | 0.016" | 0.014" | 138 cm | 5 F / 0.056" |
| 110200483 | 1.1 mm | 20 mm | 1 | 1 mm | 0.016" | 0.014" | 138 cm | 5 F / 0.056" |
The balloon material is a semi-compliant polyamide,
providing a ‘Work Your Size’.
| Balloon ⌀ | Atm 5 | Atm* 7 | Atm 9 | Atm 11 | Atm 13 | Atm 15 | Atm** 17 | Atm 19 | Atm 21 |
|---|---|---|---|---|---|---|---|---|---|
| 1.1 mm | 1.04 mm | 1.10 mm | 1.13 mm | 1.16 mm | 1.20 mm | 1.23 mm | 1.28 mm | 1.38 mm | 1.45 mm |
